Available models
|
DS-2CE10DF0T-F(2.8mm), DS-2CE10DF0T-F(3.6mm)
|
Smart Supplement Light
|
Yes
|
Korpus tipi
|
Bullet
|
Qətnamə
|
2 MP
|
Lens növü
|
2.8 mm, 3.6 mm, 6 mm fixed focal lens
|
Shutter Time
|
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
|
Focal Length & FOV
|
2.8 mm, horizontal FOV: 98°, vertical FOV: 51°, diagonal FOV: 115°3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90°6 mm, horizontal FOV: 50°, vertical FOV: 27°, diagonal FOV: 58°
|
WDR
|
DWDR
|
İşıqlandırma səviyyəsi
|
ColorVu
|
Iris Type
|
2.8 mm, 3.6 mm, 6 mm fixed focal lens
|
Qorunma standartı
|
IP67
|
Material
|
Metal
|
Lens mount
|
M12
|
Supplement Light Type
|
White Light
|
Supplement Light Range
|
Up to 20 m
|
Seriya
|
DF0T Series
|
Image Enhancement
|
DWDR, BLC, HLC, Global
|
Wide Dynamic Range (WDR)
|
Digital WDR
|
Image Parameters Switch
|
STD/HIGH-SAT/HIGHLIGHT
|
Image Settings
|
Brightness, Mirror, Sharpness, Anti-Banding, AGC
|
Power
|
12 VDC ± 25%, Max. 2.4 W*You are recommended to use one power adapter to supply the power for one camera.
|
Dimension
|
161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76")
|
Weight
|
Approx. 395 g (0.87 lb)
|
Language
|
English
|
Protection
|
IP67
|
Operating Condition
|
-40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing)
|
White Balance
|
Auto/Manual
|
Signal System
|
PAL/NTSC
|
Day/Night Mode
|
Color
|
Noise Reduction
|
3D DNR/2D DNR
|
Əlaqə
|
HIKVISION-C
|
Light Alarm
|
Solid Light Alarm (White Light)
|
