2 MP AcuSense Motorized Varifocal Turret Network Camera
SKU: DS-2CD2H23G2-IZS
Xüsusiyyətlər: 2 MP qətnamə | Varifocal motorized lens (2.8-12mm) | EasyIP 2.0 Plus with AcuSense | Turret korpus tipi | 120 dB WDR | IR əlavə işıq, 40 m məsafə | DORI məsafələri: 44.1-137.9 m | H.265 Main Profile | AI əsaslı perimetr mühafizəsi | TCP/IP, HTTP/HTTPS, ONVIF və s. protokollar | IP67 və IK10 qoruma | PoE dəstəyi | SD kart və NAS yaddaş | IR kəsici | 12 VDC və PoE enerji təchizatı | Geniş temperatur diapazonu (-30°-60°C) |
İlkin qiymət: 450.00 ₼.375.00 ₼Cari qiymət: 375.00 ₼.
Taksitlə Ödə
0 ₼
Yekun məbləğ: 0 ₼
Kreditlə ödə
0 ₼
0 ₼
Techbar mağasından yaxınlaşaraq məhsulu əldə edin
Satış təmsilçilərimiz tərəfindən Sizə ən uyğun məhsul təklif olunacaqdır.
Çatdırılma xidməti
300 AZN üzəri alışlarda şəhərdaxili çatdırılma üçün nəzərdə tutulur.
Pulsuz
DHL courier will deliver to the specified address
2-3 Days
Free
Bütün məhsullara mağaza və rəsmi servis tərəfindən zəmanət verilir.
Ödəniş üsulları:
Texniki göstəricilər
| Available models |
DS-2CD2H23G2-IZS(2.8-12mm) |
|---|---|
| H.265 Type |
Main Profile |
| Korpus tipi |
Turret |
| Qətnamə |
2 MP |
| Lens növü |
Varifocal lens, motorized lens, 2.8 to 12 mm |
| Shutter Time |
1/3 s to 1/100,000 s |
| Focal Length & FOV |
2.8 to 12 mm, horizontal FOV 106.6° to 31.7°, vertical FOV 54.7° to 17.7°, diagonal FOV 130.3° to 36.4° |
| WDR |
120 dB |
| Iris Type |
Varifocal lens, motorized lens, 2.8 to 12 mm |
| Aperture |
F1.6 |
| Lens mount |
Ø14 |
| DORI |
2.8 to 12 mm: D: 44.1 m to 137.9 m, O: 17.5 m to 54.7 m, R: 8.8 m to 27.5 m, I: 4.4 m to 13.8 m |
| Supplement Light Type |
IR |
| Supplement Light Range |
Up to 40 m |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Seriya |
EasyIP 2.0 Plus with AcuSense |
| Bit Rate Control |
CBR/VBR |
| Scalable Video Coding (SVC) |
Yes |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| API |
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK |
| AI |
Perimetr mühafizəsi |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, QoS, 802.1X, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets |
| Zəif işıqda görüntü |
Normal |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| İşıqlandırma məsafəsi |
21-50m |
| Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Yaddaş tipi |
SD Kart |
| Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Smart Supplement Light |
Yes |
| Web browser |
Plug-in required live view: IE 10, IE 11Plug-in free live view : Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+ |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Reset Key |
Yes |
| Ethernet Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Basic Event |
Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event |
Line crossing detection, intrusion detectionSupports human and vehicle targets classificationFace detection |
| Linkage |
Upload to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture, send email |
| Power |
12 VDC ± 25%, 0.92 A, max. 11 W, Ø5.5 mm coaxial power plug, reverse polarity protectionPoE: 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W |
| Dimension |
Ø138.3 × 126 mm (Ø5.4" × 5.0") |
| Weight |
Approx. 830 g (1.8 lb.) |
| With Package Weight |
Approx. 1115 g (2.5 lb.) |
| Wide Dynamic Range (WDR) |
120 dB |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Language |
33 languagesEnglish, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function |
Anti-flicker, heartbeat, password reset via email, pixel counter |
| EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
IP67 (IEC 60529-2013), IK10 (IEC 62262: 2002) |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Day & Night |
ICR Cut |
| IR Wavelength |
850 nm |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| Environment Noise Filtering |
Yes |
| Alarm |
1 input, 1 output (max. 12 VDC, 30 mA) |
| Audio |
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
