Seriya
|
D0T-LS Series
|
Supplement Light Range
|
IR : Up to 40 mWhite Light : Up to 40 m
|
Korpus tipi
|
Bullet
|
Lens növü
|
2.8 mm, 3.6 mm and 6 mm fixed focal lens
|
Shutter Time
|
PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s
|
IR məsafəsi
|
21-50m
|
Focal Length & FOV
|
2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118°3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°6 mm, horizontal FOV: 49.2°, vertical FOV:28.3 °, diagonal FOV: 56.1°
|
WDR
|
DWDR
|
İşıqlandırma səviyyəsi
|
Normal
|
Iris Type
|
2.8 mm, 3.6 mm and 6 mm fixed focal lens
|
Qorunma standartı
|
IP67
|
Material
|
Front cover: MetalMain body: Plastic
|
Lens mount
|
M12
|
Supplement Light Type
|
White Light;IR
|
Available models
|
DS-2CE17D0T-LFS(2.8mm), DS-2CE17D0T-LFS(3.6mm), DS-2CE17D0T-LFS(6mm)
|
Image Enhancement
|
Yes
|
Wide Dynamic Range (WDR)
|
Digital WDR
|
Image Settings
|
Brightness, Sharpness, Smart IR
|
Dimension
|
216.6 mm × 78.9 mm × 75.4 mm (8.53" × 3.10" × 2.97")
|
Weight
|
Approx. 339 g (0.75 lb.)
|
Language
|
English
|
Protection
|
IP67
|
Operating Condition
|
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
|
Day & Night
|
ICR
|
White Balance
|
Auto/Manual
|
AGC
|
Yes
|
Consumption
|
Max. 4.8 W
|
Signal System
|
PAL/NTSC
|
Day/Night Mode
|
IR/White Light
|
