4k AcuSense Bullet sabit çözünürlüklü şəbəkə kamerası
SKU: DS-2CD2T86G2-2I(C)
Xüsusiyyətlər: EasyIP 4.0 with AcuSense | Bullet korpus tipi | 8 MP qətnamə | 2.8, 4, və 6 mm sabit linzalar (seçim üzrə) | 120 dB WDR | IR əlavə işıq ilə 60-80 m məsafədə işıqlandırma | Darkfighter zəif işıq rejimi | Perimetr mühafizəsi AI funksiyası | H.264 və H.265 video kodlaşdırması | 256 GB-əkadə SD kart dəstəyi və NAS | IP67 su və tozdan mühafizə | PoE və 12 VDC enerji təchizatı | Multi-protokol dəstəyi | Face Capture və
İlkin qiymət: 481.00 ₼.401.00 ₼Cari qiymət: 401.00 ₼.
Mağazadan təslim
Çatdırılma xidməti
Zəmanətli məhsullar
DHL courier will deliver to the specified address
2-3 Days
Free
Ödəniş üsulları:
Texniki göstəricilər
| Available models |
DS-2CD2T86G2-2I(2.8mm)(C), DS-2CD2T86G2-2I(4mm)(C), DS-2CD2T86G2-2I(6mm)(C), DS-2CD2T86G2-4I(2.8mm)(C), DS-2CD2T86G2-4I(4mm)(C), DS-2CD2T86G2-4I(6mm)(C), DS-2CD2T86G2-2I(2.8mm)(C)(BLACK), DS-2CD2T86G2-4I(4mm)(C)(BLACK) |
|---|---|
| H.265 Type |
Main Profile |
| Qətnamə |
8 MP |
| Lens növü |
Fixed focal lens, 2.8, 4, and 6 mm optional |
| Shutter Time |
1/3 s to 1/100,000 s |
| Focal Length & FOV |
2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131°4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102°6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60° |
| WDR |
120 dB |
| Iris Type |
Fixed focal lens, 2.8, 4, and 6 mm optional |
| Aperture |
F1.6 |
| Lens mount |
M12 |
| DORI |
2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m |
| Supplement Light Type |
IR |
| Supplement Light Range |
-2I: up to 60 m -4I: up to 80 m |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Smart Supplement Light |
Yes |
| Bit Rate Control |
CBR/VBR |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| API |
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| AI |
Perimetr mühafizəsi, Var |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
| Zəif işıqda görüntü |
Powered by Darkfighter |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| İşıqlandırma məsafəsi |
51-100m |
| Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Yaddaş tipi |
SD Kart |
| Network Storage |
MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Korpus tipi |
Bullet |
| Seriya |
EasyIP 4.0 with AcuSense |
| Weight |
Approx. 1270 g (2.8 lb.) |
| Wide Dynamic Range (WDR) |
120 dB |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| SNR |
≥ 52 dB |
| Reset Key |
Yes |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Basic Event |
Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle))Scene change detection |
| Linkage |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture |
| Power |
-2I: 12 VDC ± 25%, 0.63 A, max. 7.5 W, Ø5.5 mm coaxial power plug, reverse polarity protectionPoE: 802.3af, Class 3, 36 V to 57 V, 0.25 A to 0.16 A, max. 9 W -4I: 12 VDC ± 25%, 0.88 A, max. 10.5 W, Ø5.5 mm coaxial power plug, reverse polarity protectionPoE: 802.3af, Class 3, 36 V to 57 V, 0.34 A to 0.21 A, max. 12 W |
| Dimension |
Ø105 mm × 290 mm (Ø4.1" × 11.4") |
| With Package Weight |
Approx. 1510 g (3.3 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Web browser |
Plug-in required live view: IE 10+Plug-in free live view: Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+ |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
33 languagesEnglish, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function |
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013) |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
IP67 (IEC 60529-2013) |
| Day & Night |
IR cut filter |
| IR Wavelength |
850 nm |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| Face Capture |
Yes |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Target Cropping |
Yes |
